Special features

Applies the modulating signals that fit the features of the Piezo Ceramic Technology or elements: Uses the ultrasonic modulation algorithm technology
Delivers clear sounds up to 100 meters with consistent sound pressures through the envelope modulation u

Technology features

  • 01. Equalizes sound directions based on directivity

    General speakers create an echo, overlapping sounds

    Directional speakers equalize the sound directions to minimize any overlapping sounds

  • 02. Minimizes echoes by taking into account the mirroring effect of the sounds

    Minimizes echoes when compared to general horns

  • 03. Replies occur at a consistent frequency

    Compression drivers with the ability to reply at a consistent frequency in an auditory perceptive region

  • 04. Reaches the STI of 0.46 or above on average in tunnels

    ※ STI (Speech Transmission Index)

Specification

Sound pressure(Maximum) Above 85dB(@1kHz / 1m)
Beam Angle ±10°
SNR(Signal to noise ratio) Above -60dB(@1kHz)
Modulation Frequency 40KHz
Operating temperature -25°c ~ +45°c
Dimension Speaker(+Amp) Ø123.1*46mm(D) Stand Ø102.5*123mm(D)
Output/Power consumption 23W / 8W
Power Input (Adapter) AC 100-240V / 50/60Hz, 1.7A
Power Output (Adapter) DC 19(3.42A), 24V(2.5A)
External audio input terminals 3.5Ø audio jack, RCA jack input
Bluetooth Bluetooth 4.0
Frequency range 400Hz ~ 10KHz
